High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm

High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm

  • High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm
  • High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm
  • High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm
High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm
Product Details:
Place of Origin: China
Brand Name: YIXIN TITANIUM
Certification: NORSOK M650， AS 9100
Model Number: Dia:136*925mm
Payment & Shipping Terms:
Minimum Order Quantity: 50KG
Packaging Details: Polywood cases
Delivery Time: 15 days
Payment Terms: T/T, L/C, Western Union, MoneyGram, D/P
Supply Ability: 200ton per month
Contact Now
Detailed Product Description
Material Element: Ti-6Al-4V Weight: 4.51g/cm3
Application: Aircraft Bulkhead,connector,fasteners Tensile Strength: 948MPA
Yield Strength: 863MPA Size: Dia 134mm

High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm





Chemical composition of Grade 5  titanium bar: Fe≤0.25, Al :5.5-6.5, V:3.75-4.5, O≤0.20, C≤0.05, N≤0.03, H≤0.015 Ti: allowance;



Grade 5 Titanium bar physical characteristics:

1.Light texture, low density, high specific strength.Density 4.45kg/CM3, lighter than most metals,
Tensile strength ≥ 895Mpa, yield strength ≥ 825Mpa, elongation ≥ 8%

2 hardness, wear resistance, so often used to do mold abrasive

3. Good high temperature resistance. Compared with pure titanium, the high temperature resistance of TC4 titanium alloy is significantly improved, and it can work for a long time under 500°C.

Application of Gr5 titanium rod: widely used in electric power, petroleum equipment, Marine ships, chemical equipment, electronic instruments, automotive industry, etc.It is currently the most widely used and the largest amount of titanium alloy.
Grade 5 alloy is much cheaper than other titanium alloy materials
Titanium materials produced by our company: superior materials, excellent processing, ingredients, performance, flaw detection and other tests before leaving the factory, to ensure product quality standards.



Chemical Test





Material grade AL V Fe O C N H
Gr5 6.13 4.17 0.15 0.145 0.011 0.008 0.0006



Mechanical Test



Material grade Tensile Strength Yield Strength Elongation Reduction of Area
Gr5 948 863 16.5 47


Mechanical properties



High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm 0



Chemical compositon



High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm 1



Material list

High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm 2

Product Related photos

High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm 3High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm 4High Strength Anti-Corrosion And Wear Resistance Gr5 Titanium Round Bar Dia 134mm 5
