Shaanxi High-end Industry &Trade Co., Ltd.
Commit to Qualified Products & Service in Nonferrous Metal Supply. AS9100& Norsok M650 qualified factory.
 |
| Place of Origin: | MADE IN CHINA |
| Brand Name: | YIXIN TITANIUM |
| Certification: | AS9100 and NORSOK M650 qualified |
| Model Number: | ASTM B550 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Packaging Details: | Plywooden case |
| Delivery Time: | 15DAYS |
| Payment Terms: | T/T, D/P, Western Union, MoneyGram |
| Supply Ability: | 100 tons per month |
| Technique: | Forged And Machined Ring | Grade: | R60702 |
|---|---|---|---|
| Dimensions: | OD232MM | Density: | 6.5 G/cm3 |
| Standard: | ASTM B550 | Powder Or Not: | Not Powder |
| High Light: | ZR60702 Titanium Forging,ASTM B550 Titanium Forging,ZR60702 titanium alloy ring |
||
ASTMB550 ZR60702 Pure Zirconium Bar Forged OD232MM With UT Level A Tested
Product
The main applications include pressure vessels, heat exchangers, pipes, tanks, shafts, agitators and other mechanical equipment as well as valves, pumps, sprayers and tower linings, especially acetic acid, pesticides, plastics and other industries are widely used.
Chemical Test
| Material | Cr | Hf | Fe | O | C | N | H |
| ZR60702 | 0.014 | 1.92 | 0.096 | 0.145 | 0.006 | 0.003 | 0.0006 |
Mechanical Properties
| Material | Tensile | Yield | EL | Re |
| ZR60702 | 438 | 271 | 25 | 46 |
Details
| Material | Zr60702 |
| Standard | ASTMB550,ASTMB493 |
| Mechanical properties | 426MPA/269MPA/27%/44% |
| Tested |
Destractive testing with sample from product, UT 100%(AMS2631E), PT 100%(ASTM E165) |
| Hardness | MIN179 HBW |
| Dimension | 232*120*132.5mm , 175*90*89mm |
Chemical composition
Mechanical properties
MTC From YIXIN
